| HARDWARE FEATURES |  |
| Standards and Protocols | IEEE 802.3, 802.3u, 802.3x, TCP/IP, DHCP, ICMP, NAT, PPPoE, SNTP, HTTP, DDNS |
| Interface | 1 Fixed Ethernet WAN Port 1 Fixed Ethernet LAN Port
 3 Changeable Ethernet WAN/LAN Ports
 |
| Network Media | 10BASE-T: UTP category 3, 4, 5 cable (Max 100m) 100BASE-TX: UTP category 5, 5e cable (Max 100m)
 |
| Button | Reset Button |
| Power Supply | Internal Universal Power Supply AC100-240V~50/60Hz input
 |
| Flash | 8MB |
| DRAM | 64MB |
| LED | PWR, SYS, WAN, LAN, WAN/LAN |
| Dimensions ( W x D x H ) | 11.6*7.1*1.7in. (294*180*44mm) 13-inch Standard Rack-Mount Width, 1U Height
 |
| PERFORMANCE |  |
| Concurrent Session | 30000 |
| BASIC FUNCTIONS |  |
| WAN Connection Type | Static/Dynamic IP, PPPoE, PPTP, L2TP, Dual Access, Bigpond Cable |
| MAC Clone | Modify WAN/LAN MAC Address |
| DHCP | DHCP Server/Client, DHCP Address Reservation |
| Switch Setting | Port Mirror, Rate Control, Port Configuration, Port VLAN |
| ADVANCED FUNCTIONS |  |
| ACL | IP/MAC/URL/WEB Filtering |
| IGMP | IGMP Proxy/IGMP Snooping |
| Forwarding | Virtual Server, Port Triggering, DMZ |
| Load Balance | Policy Routing, Link Backup |
| NAT | One-to-One NAT, Multi-Nets NAT |
| Routing | Static Routing |
| Security | FTP/SIP/PPTP/IPsec/H.323 ALG, DoS Defence, Ping of Death |
| Traffic Control | Bandwidth Control, Session Limit |
| MANAGEMENT |  |
| Service | PPPoE Server, E-Bulletin, Dynamic DNS, UPnP, App Control |
| Maintenance | Time Setting, Daylight Saving Time, SNMP, Diagnostics, Firmware Upgrade, Factory Defaults/Reboot, Backup/Restore, System Log, Remote Management, Statistics |
| OTHERS |  |
| Certification | CE, FCC, RoHS |
| Package Contents | TL-R480T+ Power Cord
 RJ-45 Ethernet Cable
 Installation Guide
 Resource CD
 |
| System Requirements | Microsoft Windows 98SE, NT, 2000, XP, Vista™ or Windows 7, MAC OS, NetWare, UNIX or Linux |
| Environment | Operating Temperature: 0°C~40°C (32°F~104°F) Storage Temperature: -40°C~70°C (-40°F~158°F)
 Operating Humidity: 10%~90% non-condensing
 Storage Humidity: 5%~90% non-condensing
 |
