| CAMERA |
| Image Sensor |
1/2.7" Progressive Scan CMOS Sensor |
| Lens |
Focal Length: 4.0 mm
Aperture: F1.6
Field of View: 105.4° (Diagonal), 88.0°(Horizontal), 46.0°(Vertical) |
| Motion Range |
Pan Mechanical Range: 340° (360° Pan Coverage)
Tilt Mechanical Range: 180° (130° Tilt Coverage) |
| Night Vision |
Infrared Night Vision (52 ft / 16 m)
Color Night Vision (52 ft / 16 m) |
| Lighting |
2× Built-in Spotlights |
| Interface & Button |
1× Power Button
1× RESET Button
1× MicroSD Card Slot (Up to 512GB) |
| SOLAR PANEL |
| Connection Capacity |
A solar panel can only connect to one camera. |
| Output Port |
Type-C |
| VIDEO & AUDIO |
| Maximum Resolution |
3K 5MP (2880 × 1620 px) |
| Frame Rate |
15 fps |
| Digital Zoom |
45790 |
| Video Compression |
H.264 |
| Live View |
YES |
| Image Enhancement |
3DNR
WDR |
| Audio Input & Output |
Built-in Microphone and Speaker |
| Audio Communication |
Two-Way Audio with Noise Cancellation |
| Siren Volume |
78.9 dBA (Level measured at 10 cm distance) |
| STORAGE |
| Local Storage |
MicroSD Card Slot on Camera (Up to 512 GB, microSD card not included) |
| Cloud Storage |
Tapo Care Cloud Storage Services (Subscription required) |
| DETECTION and NOTIFICATIONS |
| Sensor |
Motion Sensor
Ambient Light Sensors |
| AI Detection |
Motion Detection
Person Detection
Vehicle Detection
Pet Detection |
| Activity Zones |
Yes |
| Output Notification |
System Notification
System Notification with Snapshot (Tapo Care Services) |
| NETWORK |
| Network Connectivity |
Connect via Wi-Fi |
| Wireless Connectivity |
IEEE 802.11b/g/n, 2.4 GHz Wi-Fi |
| SECURITY |
| Security |
128-bit AES Encryption with SSL/TLS
WPA/WPA2-PSK |
| POWER |
| Power Source |
5V DC Power Adapter (Not Included)
6700 mAh Built-in Rechargeable Lithium-ion Battery
Solar Panel: Tapo A201 |
| Input Voltage |
5.0 V, 2.0 A |
| Output Voltage |
/ |
| GENERAL |
| Smart Integration |
Google Assistant, Amazon Alexa |
| Weather Resistance |
IP65 for both camera and solar panel |
| System Requirements |
Tapo App: iOS 12.0 or higher, Android 7.0 or higher |
| Mounting Options |
Wall-Mounted
Eave-Mounted
Pole-Mounted (Pole-Mounting loops required but not included) |
| Operating Temperature |
-20°C to 45°C (-4°F to 113°F) |
| Storage Temperature |
-40°C to 60°C (-40°F to 140°F) |
| Operating Humidity |
10%~90% RH, Non-condensing |
| Storage Humidity |
0%~90% RH, Non-condensing |
| Charging Temperature |
0°C to 45°C (32°F to 113°F) |
| Dimensions ( W x D x H ) |
Camera Dimensions: 141 x 128 x 84 mm (5.55 x 5.04 x 3.31 in)
Solar Panel Dimensions: 173.4 x 120.4 x 15.7 mm (6.83 x 4.74 x 0.618 in) |
| Package Content |
Tapo C630 Camera × 1
Tapo A201 Solar Panel × 1
Tapo A201 Solar Panel Bracket × 1
Base Cover × 1
USB Adapter Cable × 1
Extension Wire × 1
Cable Zip Tie × 1
Mounting Screws and Anchors
Mounting Template Stickers
Quick Start Guide |
| Certifications |
CE, FCC, JRF, VCCI, RCM, NTRA, NCC, BSMI, DOE, CEC, IP65, RoHS |
