| S/W |
|
| MCU Name |
RoseP |
| etc |
WorldWide |
| T-CON Update |
Yes |
| Core Component |
|
| DDR SDRAM |
Samsung |
| Nand Flash Memory |
Samsung |
| OneNand Flash Memory |
N/A |
| FlexOneNand Flash Memory |
N/A |
| Serial Flash Memory |
WINBOND |
| HDMI Switch |
N/A |
| Display Device Vender |
SDC |
| Operation Condition |
|
| Temperature (?) |
0?~40? |
| Humidity (%) |
10%~80%, Non-Condensing |
| Storage Conditions Temperature (?) |
-20?~45? |
| Storage Conditions Humidity (%) |
5%~95%,, Non-Condensing |
| Power |
|
| Type (Internal/External) |
External Adaptor |
| Power Supply Spec. |
AC100-240V 50/60Hz |
| Power Consumption(Max) (W) |
N/A |
| Power Consumption(Typical) (W) |
N/A |
| Power Consumption (DPMS) (W) |
N/A |
| Power Consumption (Off Mode) (W) |
N/A |
| Power Consumption (Yearly) (kWh/year) |
N/A |
| Power Consumption(Rating) |
N/A |
| AC Input Power Freq. (Hz) |
50/60Hz |
| SMPS/IP Board/Adapter |
DongYang E&P |
| Design |
|
| Color (Front) |
SILVER |
| Color (Rear) |
SILVER |
| Color (Stand Base) |
Silver |
| Stand Type |
HAS PIVOT |
| Height Adjustable Range |
120.0 ±5.0 |
| Tilt Range |
-2.0° (±2.0°) ~ 25.0° (±2.0°) |
| Swivel Range |
-30° (±3.0°) ~ +30° (±3.0°) |
| Pivot |
-92.0° (±2.0°) ~ +92.0° (±2.0°) |
| Wall Mount |
100 x 100 |
| Function Key Type (Touch/Tactile/Joystick/One-key) |
Joystick |
| Lighting |
Yes |
| Label Rating |
N/A |
| Injection Mode |
Normal |
| Front Resin |
N/A |
| Stand Packing Type |
ONE PACKING |
| Dimension (WxHxD) |
|
| Set without Stand (mm) |
719.7 x 414.7 x 49.2 |
| Set with Stand (mm) |
719.7 x 584.6 x 263.5 |
| Package Dimension (mm) |
815 x 200 x 530 |
| Stand Dim (WxD) |
|
| Stand (Basic) |
296.1 x 263.5 |
| Stand (Minimum) |
N/A |
| Weight |
|
| Set Weight without Stand (kg) |
5.3 |
| Set Weight with Stand (kg) |
8.4 |
| Package Weight (kg) |
10.9 |
| Accessory |
|
| D-Sub Cable |
N/A |
| DVI Cable |
N/A |
| HDMI Cable |
Yes |
| HDMI to DVI Cable |
N/A |
| Display Port Cable |
Yes |
| USB A To B |
N/A |
| USB Type-C Cable |
N/A |
| USB Type-C to Type-A Gender Cable |
N/A |
| Thunderbolt Cable |
N/A |
| HDMI to Micro HDMI Cable |
N/A |
| Mini-Displayport to Display Port Cable |
N/A |
| Camera |
N/A |
| External Adapter |
Normal |
| Power Cable |
1.5 m |
| Clean Cloth |
N/A |
| Install CD |
N/A |
| Manual Book |
N/A |
| QSG |
Yes |
| Warranty Card |
Yes |
| Remote Controller |
Yes |
| Remote Controller Model |
TM2360E |
| Batteries (for Remote Control) |
N/A |
| E-Manual |
Yes |
| Pogo Gender |
N/A |
| Zigbee / Thread Module |
N/A |
| Certification |
|
| Energystar |
N/A |
| TCO Certified |
N/A |
| EPEAT |
N/A |
| TUV |
Yes |
| GS |
N/A |
| Low Blue Light |
Yes |
| Flicker Free |
Yes |
| Intelligent Eye Care |
N/A |
| Eye comfort 1000R |
N/A |
| Product Carbon Footprint |
N/A |
| UL Glare free |
Yes |
| Pantone Validated |
N/A |
| VESA CMR |
N/A |
| Eco |
|
| Energy Efficiency Class |
N/A |
| Recycled Plastic |
Yes |
| Software Support |
|
| Security Update Period (At least 5 years) |
N/A |
| [SMART] Video / Audio |
|
| Expert Calibration |
N/A |
| Smart Calibration |
Basic |
| AI Upscale |
Yes |
| Dolby Decoder |
MS12 2ch |
| Q-Symphony |
N/A |
| 360 Audio |
Yes |
| Active Voice Amplifier Pro |
Yes |
| Adaptive Sound |
Adaptive Sound Pro |
| Multiroom Link |
Yes |
| [SMART] Smart Service |
|
| Smart Type |
Smart |
| Operating System |
Tizen™ |
| Bixby |
Yes |
| Far-Field Voice Interaction |
Yes |
| Built-in Voice Assistant |
Alexa (GB, DE, FR, IT, ES, AT, IE) |
| TV Plus |
Yes (GB, FR, DE, IT, ES, CH, AT, NL, SE, NO, DK, FI, PT, IE, BE, LU) |
| Web Browser |
Yes |
| SmartThings Hub / Matter Hub / IoT-Sensor Funtionality |
Yes |
| Samsung Health |
Yes (GB, IE Only) |
| Universal Guide |
Yes (GB, FR, DE, IT, ES) |
| Media Home |
Yes |
| 3rd party Service Certification / Agreement |
Yes |
| [SMART] Smart Feature |
|
| Multi Device Experience |
Mobile to Screen, Screen initiate mirroring, Sound Mirroring, Wireless On, Tap View |
| TV Access |
Yes |
| Multi View |
upto 2 videos |
| External Source Support |
2 |
| My Contents |
Yes |
| Flex Move Screen |
N/A |
| Workspace |
N/A |
| Easy Setup |
Yes |
| Chat Togethter |
N/A |
| NFT |
Nifty Gateway |
| ConnecTime |
N/A |
| ScreenVitals |
N/A |
| Buds Auto switch |
Yes |
| Daily+ |
Yes |
| Workout Tracker |
Yes |
| Multi Control |
Yes |
| Now+ |
Now+ |
| Knox Vault |
N/A |
| 9:16 Screen Support |
Yes |
| DPMS |
Yes |
| Accessibility - Voice Guide |
Yes |
| Accessibility - Low Vision Support |
Enlgarge, High Contrast, SeeColors, Color Inversion, Grayscale, Picture Off |
| Accessibility - Hearing Impaired Support |
Multi-output Audio, Sign Language Zoom |
| Accessibility - Motor Impaired Support |
Slow Button Repeat |
| Caption (Subtitle) |
Yes |
| ConnectShare™ |
Yes |
| EPG |
Yes |
| MBR Support |
Yes |
| Localization |
|
| AoT |
N/A |
| Local IoT Support |
N/A |
