Unique Feature
Superb Productivity- PCIe Gen5 (Graphics, M.2)- Eight Channel DDR5- USB4 Type-C Ports (40 Gb/s)Rock-Solid Durability- Ultra Low-Loss PCB- 18+3+3 Power Phase, 110A SPS for VCore- 20K Long-lasting Black Caps (high quality and conductive polymer capacitors)Ultrafast Connectivity- Dual Intel 10G LANEZ Update- ASRock Auto Driver Installer
CPU
- Supports AMD Ryzen™ Threadripper™ PRO 9000/7000 WX-Series Processors- Supports AMD Socket sTR5- Supports ASRock Hyper BCLK Engine
Chipset
- AMD WRX90
Memory
- Eight Channel DDR5 Memory Technology- 8 x DDR5 DIMM Slots*- Supports DDR5 ECC, buffered memory (RDIMM/ RDIMM-3DS) up to 7600+(OC)- Max. capacity of system memory: 2TB
BIOS
- 256Mb AMI UEFI Legal BIOS with GUI support
Graphics
- Aspeed AST2600 BMC Controller- 1 x DisplayPort 1.1a with max. resolution up to 1920x1200 @ 60Hz*
Audio
- 7.1 CH HD Audio with Content Protection (Realtek ALC1220 Audio Codec)- Impedance Sensing on Rear Out port- Individual PCB Layers for R/L Audio Channel- Nahimic Audio
LAN
2 x 10 Gigabit LAN 100/1000/2500/5000/10000 Mb/s (Intel X710-AT2)- Support PXE1 x Dedicated IPMI (Realtek RTL8211F)
Slots
CPU:- 7 x PCIe 5.0 x16 Slots (PCIE1/PCIE2/PCIE3/PCIE4/PCIE5/PCIE7 at x16; PCIE6 at x8)*- 15µ Gold Contact in VGA PCIe Slots
Storage
CPU:- 1 x Blazing M.2 Socket (M2_1, Key M), supports type 2260/2280/22110 PCIe Gen5x4 (128 Gb/s) mode*- 2 x MCIO Connectors (PCIe Gen5x4 or 4 x SATA3 6.0 Gb/s)- 1 x SlimSAS SFF-8654 Connector (SLIM1) (PCIe Gen4x4 or 4 x SATA3 6.0 Gb/s)Chipset:- 1 x Hyper M.2 Socket (M2_2, Key M), supports type 2260/2280 PCIe Gen4x4 (64 Gb/s) mode*- 1 x SlimSAS SFF-8654 Connector (SLIM2) (PCIe Gen4x4)- 4 x SATA3 6.0 Gb/s Connectors- Supports RAID 0, RAID 1 and RAID 10 for SATA storage devices- Supports RAID 0, RAID 1 and RAID 10 for M.2 NVMe storage devices
USB
CPU:- 2 x USB4 Type-C (Rear)- 4 x USB 3.2 Gen2 Type-A (Rear)Chipset:- 1 x USB 3.2 Gen2x2 Type-C (Front)- 4 x USB 3.2 Gen1 Type-A (2 Rear, 2 Front)- 4 x USB 2.0 (Front)
Internal I/O
- 2 x Thermistor Cable Headers- 1 x Front VGA Header- 1 x COM Port Header- 1 x Power LED and Speaker Header- 1 x Intelligent Platform Management Bus Header- 1 x PSU SMBus Header- 1 x BMC SMBus Header- 1 x Auxiliary Panel Header- 2 x Addressable LED Headers*- 1 x CPU Fan Connector (4-pin)**- 1 x CPU/Water Pump Fan Connector (4-pin) (Smart Fan Speed Control)***- 3 x Chassis/Water Pump Fan Connectors (4-pin) (Smart Fan Speed Control)****- 1 x 24 pin ATX Power Connector (Hi-Density Power Connector)- 1 x 3 pin ATX Power Connector*****- 2 x 8 pin ATX 12V Power Connectors (Hi-Density Power Connector) (for Motherboard)******- 2 x 6 pin PCIe 12V Power Connectors (Hi-Density Power Connector) (for Motherboard)******- 2 x 6 pin Graphics 12V Power Connectors (Hi-Density Power Connector) (for PCIe card)*******- 1 x Right Angle Front Panel Audio Connector- 2 x USB 2.0 Headers (Support 4 USB 2.0 ports)- 1 x USB 3.2 Gen1 Header (Supports 2 USB 3.2 Gen1 ports)- 1 x Front Panel Type C USB 3.2 Gen2x2 Header (20 Gb/s)- 2 x SGPIO Headers- 1 x CPU HP-SMBus Connector- 1 x Non Maskable Interrupt Button Header- 1 x Dr. Debug with LED- 1 x Power Button with LED- 1 x Reset Button with LED- 1 x Clear CMOS Button
Rear Panel I/O
- 1 x DisplayPort 1.1a- 1 x Optical SPDIF Out Port- 2 x USB4 Type-C Ports (40 Gb/s)*- 4 x USB 3.2 Gen2 Type-A Ports (10 Gb/s)- 2 x USB 3.2 Gen1 Type-A Ports- 2 x RJ-45 LAN Ports- 1 x RJ45 Dedicated IPMI LAN Port- 1 x Line Out Jack (Gold Audio Jack)- 1 x Microphone Input Jack (Gold Audio Jack)
Software and UEFI
Software- ASRock Polychrome SYNC*UEFI- ASRock Full HD UEFI- ASRock Auto Driver Installer- ASRock Instant Flash
Accessories
- 1 x User Manual- 1 x I/O Shield- 4 x SATA Data Cables- 2 x Thermistor Cables- 1 x Multi PSU Adaptor Cable- 2 x Screws for M.2 Sockets- 2 x Standoffs for M.2 Sockets
Form Factor
- EEB Form Factor: 12.0-in x 13.0-in, 30.5 cm x 33.0cm- 14 Layer PCB- 2oz Copper PCB
OS
- Microsoft Windows 11 64-bit
- FCC, CE- ErP/EuP ready (ErP/EuP ready power supply is required)- CEC Tier II ready
