Frequency Range
80Hz-20kHz
*Frequency characteristic measured at anechoic chamber
Horizontal Dispersion
200 degrees
*1 - 4k average?-6 dB *At Vertical style (Vertical Dispersion at Horizontal style
Vertical Opening Angles
Software Adjustable:
1 Module: Max 40 degrees
2 Modules: Max 50 degrees
3 Modules: Max 60 degrees
4 Modules: Max 70 degrees
5 Modules: Max 80 degrees
6 Modules: Max 90 degrees
*At Vertical style(Vertical Opening Angles at Horizontal style)
Vertical Beam Steering Angles
1 Module: 20 degrees
2 Modules: 20 degrees
3 Modules: 30 degrees
4 Modules: 30 degrees
5 Modules: 40 degrees
6 Modules: 40 degrees
*At Vertical style(Vertical Opening Angles at Horizontal style)
Maximum SPL (1 m)
1 Module: 105 dB (peak 112 dB)
2 Modules: 111 dB (peak 118 dB)
3 Modules: 115 dB (peak 122 dB)
4 Modules: 117 dB (peak 124 dB)
5 Modules: 119 dB (peak 126 dB)
6 Modules: 121 dB (peak 128 dB)
* Max SPL calculated based on free-field sensitivity, and without beam steering, spreading applied.
Peak SPL (30 m)
1 Module 97 dB
2 Modules: 103 dB
3 Modules: 107 dB
4 Modules: 109 dB
5 Modules: 111 dB
6 Modules: 113dB
* Assumption signal loss at 30 m and 15 dB
Typical Usable Throw Distance
1 Module: 4m
2 Modules: 8m
3 Modules: 12m
4 Modules: 16m
5 Modules: 20m
6 Modules: 25m
*Typical Maximum Usable Throw Distance includes considerations for reverberation and speech intelligibility
Low-frequency Beam Control Limit
1 Module: 1.25 kHz
2 Modules: 630 Hz
3 Modules: 400 Hz
4 Modules: 315 Hz
5 Modules: 250 Hz
6 Modules: 200 Hz
Enclosure type
Bass reflex type
Driver
Flat and Square speaker unit, 35 mm x 35 mm (1 7/16 in × 1 7/16 in) Full range x 8
Dust and water resistant
No
Amplifier Channels /
Rated Power
Power Output (rated)
10 W x 8 channels (at 6 ohms, 1 kHz, 1 % THD)
Protection circuit
Speaker Processing: Clipping limit
Amplifier: Terminal shutdown/Overheat protection/Over voltage protection/Under voltage lock out/DC protection
Power: Overload protection/Overheat protection
