| 80PLUS certification |
Platinum |
| Modular cables |
Fully Modular |
| Fan type |
140 mm FDB bearing Fractal Design Dynamic series fan |
| Maximum operating temperature (full load) |
50°C |
| Semi-passive operation |
Yes, user selectable (Zero RPM) |
| Capacitors |
Japanese |
| Life expectancy |
100,000 hours |
| Cable type |
Modular 24-pin cable: Black UltraFlex™ wires in braided sleeve Other modular cables: Flat black UltraFlex™ wires |
| Input voltage |
100-240V C |
| Input frequency |
50-60 Hz |
| Input current |
10A/5A |
| Protection features |
Over voltage protection, Under voltage protection, Overpower protection, Short circuit protection, Over current protection, Over temperature protection |
| PSU specification compliance |
ATX12V 2.52; EPS12V 2.92 |
| Sleep state compliance |
C6/C7 |
| Approvals & certifications |
CE, FCC, TUV, cTUVus, EAC, RCM, CCC, BSMI, CB, KC+KCC |
| Warranty |
10 years |
| Connectors |
| ATX 24-pin |
1 |
| ATX12V 4+4 pin / EPS12V 8-pin |
2 |
| PCIe 6+2 pin |
6 |
| SATA |
10 |
| Peripheral |
4 |
| DC Output |
| 3.3V |
22A |
| 5V |
22A |
| 3.3V and 5V combined |
120W |
| 12V |
63.3A |
| -12V |
0.3A |
| +5Vsb |
3A |
| Total Power |
760W |
| Cable Configuration (length in mm between connectors) |
| ATX 20+4 pin |
600 |
| ATX 12V 4+4 pin |
700 |
| EPS12V 8-pin |
600 |
| PCIe 6+2 pin |
550+120 |
| SATA |
400+150+150+150 mm & 650+150mm |
| Peripheral |
400+150+150+150 mm |
