| 3.5"/2.5" Universal drive mounts |
2 (included) |
| Dedicated 2.5" drive mounts |
4 (2 included) |
| Expansion slots |
7 |
| Front interface |
1x USB 3.1 Gen 2 Type-C, 2x USB 3.0, Audio I/O, Power button, Reset button |
| Total fan mounts |
7x 120 or 4x 140 mm and 2x 120 mm |
| Front fan |
3x 120 or 2x 140 mm, (2x Dynamic X2 GP-14 included) |
| Top fan |
2x 120/140 mm |
| Rear fan |
1x 120 mm, (1x Dynamic X2 GP-12 included) |
| Bottom fan |
1x 120 mm (requires removal of HDD cage) |
| Dust filters |
Top, front and bottom |
| Fixed velcro straps |
Yes |
| Cable routing grommets |
Yes |
| Captive thumbscrews |
HDD, SSD and PSU brackets |
| Left side panel |
Steel |
| Right side panel |
Steel |
| Compatibility |
| Motherboard compatibility |
ATX / mATX / Mini-ITX |
| Power supply type |
ATX |
| Front radiator |
Up to 360/280 mm |
| Top radiator |
Up to 240 mm |
| Rear radiator |
120 mm |
| Bottom radiator |
120 mm (requires removal of HDD cage) |
| PSU max length |
200 mm (165 mm with HDD cage and front fan) |
| GPU max length |
341 mm (360 mm without front fan) |
| CPU cooler max height |
169 mm |
| Cable routing space |
17-28 mm |
| Radiator Support – Additional Details |
Maximum radiator width: 145mm for front mounting. Maximum motherboard component height for top mounted radiator: 40 mm. For more details, consult the manual. |
| Dimensions |
| Case dimensions (L x W x H) |
424 x 210 x 475 mm |
| Case dimensions w/o feet/protrusions/screws |
412 x 210 x 455 mm |
| Net weight |
Solid: 7.7 kg TG: 8.1 kg |
| Package dimensions (L x W x H) |
542 x 320 x 554 mm |
| Gross weight |
Solid: 9.3 kg TG: 9.8 kg |
| Volume |
39.4 Liters |
