| GENERAL |
|
| PN |
23326 |
| EAN code |
8713439233261 |
| Warranty |
2 years |
| Package contents |
UPS unit
Power cable
User guide
Wall plugs and screws |
| System requirements |
Grounded wall power connection |
| Height of main product (in mm) |
93 mm |
| Width of main product (in mm) |
202 mm |
| Depth of main product (in mm) |
293 mm |
| Weight of main unit |
4400 g |
| Total weight |
4550 g |
| |
|
| CONNECTIVITY |
|
| Cables included |
Yes Power cable |
| |
|
| FEATURES |
|
| Software |
no |
| Management function (USB) |
no |
| Audible alarm |
yes |
| |
|
| PROTECTION |
|
| Protections |
child safety shutter, over-charge, over-discharge, over-load |
| Auto Voltage Regulation |
yes |
| RFI-filter |
no |
| Surge protected AC outlets |
yes |
| Surge protected phone line |
no |
| |
|
| POWER |
|
| Battery composition (Alkaline, Li-ion, etc.) |
Lead Acid |
| Battery capacity (Ah) |
7 Ah |
| Battery capacity (V) |
12 V |
| Number of batteries |
1 |
| |
|
| INPUT |
|
| Nominal input voltage |
220-240Vac |
| Operating voltage range |
162-290Vac |
| |
|
| OUTPUT |
|
| Frequency response UPS |
50Hz +/- 1Hz |
| Output voltage range |
nominal voltage +/- 10% |
| Waveform type |
simulated sine wave |
| |
|
| CONTROL |
|
| Indicators |
Power on/off, Overload, Battery |
