| HARDWARE FEATURES | |
| Standards and Protocols | IEEE 802.3, 802.3u, 802.3x, TCP/IP, DHCP, ICMP, NAT, PPPoE, SNTP, HTTP, DDNS |
| Interface | 1 Fixed Ethernet WAN Port
1 Fixed Ethernet LAN Port
3 Changeable Ethernet WAN/LAN Ports |
| Network Media | 10BASE-T: UTP category 3, 4, 5 cable (Max 100m), 100BASE-TX: UTP category 5, 5e cable (Max 100m) |
| Button | Reset Button |
| Power Supply | Internal Universal Power Supply
AC100-240V~50/60Hz input |
| Flash | 4MB |
| DRAM | 64MB |
| LED | PWR, SYS, WAN, LAN, WAN/LAN |
| Dimensions ( W x D x H ) | 8.2*5.0*1.0in. (209*126*26mm) |
| PERFORMANCE | |
| Concurrent Session | 10000 |
| BASIC FUNCTIONS | |
| WAN Connection Type | Static/Dynamic IP, PPPoE, PPTP, L2TP, Dual Access, Bigpond Cable |
| MAC Clone | Modify WAN/LAN MAC Address |
| DHCP | DHCP Server/Client, DHCP Address Reservation |
| Switch Setting | Port Mirror, Rate Control, Port Configuration, Port VLAN |
| ADVANCED FUNCTIONS | |
| ACL | IP/MAC/URL/WEB Filtering |
| IGMP | IGMP Proxy/IGMP Snooping |
| Forwarding | Virtual Server, Port Triggering, DMZ |
| Load Balance | Policy Routing, Link Backup |
| Routing | Static Routing |
| Security | FTP/SIP/PPTP/IPsec/H.323 ALG, DoS Defence, Ping of Death, IP/MAC Binding |
| Traffic Control | Bandwidth Control, Session Limit |
| MANAGEMENT | |
| Service | PPPoE Server, E-Bulletin, Dynamic DNS, UPnP |
| Maintenance | Time Setting, Daylight Saving Time, SNMP, Diagnostics, Firmware Upgrade, Factory Defaults/Reboot, Backup/Restore, System Log, Remote Management, Statistics |
| OTHERS | |
| Certification | CE, FCC, RoHS |
| Package Contents | TL-R470T+
Power Cord
RJ-45 Ethernet Cable
Quick Installation Guide
Resource CD |
| System Requirements | Microsoft Windows 8, 7,Vista™, XP or MAC OS, NetWare, UNIX or Linux |
| Environment | Operating Temperature: 0°C~40°C (32°F~104°F)
Storage Temperature: -40°C~70°C (-40°F~158°F)
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~90% non-condensing |
