| CAMERA |
| Image Sensor | 1/2.7“ Progressive Scan CMOS Sensor |
| Lens | Focal Length: 1.18mm
Aperture: F1.8
Field of View: 170.6° (Horizontal), 140.1° (Vertical) |
| Night Vision | 850 nm IR LED (33 ft / 10 m)
Full-Color Night Vision |
| Lighting | Built-in Spotlights |
| Interface & Button | 1× RESET /SYNC Button
1× Doorbell Button
1× Anti-Theft Button
1× Power ON/OFF Button |
| VIDEO & AUDIO |
| Maximum Resolution | 2K 5MP (2560 × 1920px) |
| Frame Rate | 15/20 fps |
| Video Compression | H.264 |
| Live View | Yes |
| Image Enhancement | 3DNR
WDR |
| Audio Input & Output | Built-in Microphone and Speaker |
| Audio Communication | Two-Way Audio with Noise Cancellation |
| Siren Volume | 98dB (Level measured at 4-inch/10-cm distance) |
| STORAGE |
| Local Storage | MicroSD Card Slot (Up to 512 GB) |
| Cloud Storage | Tapo Care Cloud Storage Services (Subscription required) |
| DETECTION and NOTIFICATIONS |
| Sensor | Single PIR Motion Sensor (FOV: 130° horizontal)
One Ambient Light Sensor |
| AI Detection | Motion Detection
Person Detection
Pet Detection
Vehicle Detection
Package Detection |
| Activity Zones | Yes
*Only works with Motion Detection. |
| Output Notification | System Notification
System Notification with Snapshot (Tapo Care Services) |
| NETWORK |
| Network Connectivity | IEEE 802.11b/g/n, 2.4 GHz Wi-Fi |
| SECURITY |
| Security | On-Device Machine Learning
128-bit AES Encryption with SSL/TLS
WPA/WPA2-PSK |
| POWER |
| Power Source | 10000 mAh Built-in Rechargeable Lithium-ion Battery
|
Hardwire charge
Hardwire supply
| Input Voltage | Doorbell Battery Pack Adapter Input: 100-240 V, 50/60 Hz |
| Output Voltage | Doorbell Battery Pack Adapter Output: 5.0 V, 2.0 A |
| GENERAL |
| Smart Integration | Google Assistant, Amazon Alexa |
| Weather Resistance | IP66 |
| System Requirements | Tapo App: iOS 12.0 or higher, Andriod 4.4 or higher |
| Mounting Options | Stick to a Wall
Mount to a Wall |
| Operating Temperature | -20?~45? |
| Storage Temperature | -40?~60? |
| Operating Humidity | 10%~90% RH, Non-condensing |
| Storage Humidity | 0~90% RH, Non-condensing |
| Charging Temperature | 0-45? |
| Dimensions | Doorbell Dimensions: 5.91 × 1.97 × 1.52 in (150 × 50 × 38.4 mm)
Chime Dimensions:
US/JP Version: 2.87×1.85×1.71 in (73×46.9×43.5 mm)
EU Version: 2.87 × 2.15 × 1.89 in (73×54.6×48 mm)
UK Version: 2.87×2.45×1.71 in (73×62.3×43.5 mm)
KR Version: 2.87×2.46×1.71 in (73×62.4×43.5mm)
AU Version: 2.87×2.01×1.71 in (73×51×43.5 mm) |
| Package Contents | Tapo Video Doorbell × 1
Tapo Chime × 1
Mounting Template × 1
Mounting Bracket × 1
Vertical Mounting Wedge× 1
Horizontal Mounting Wedge × 1
USB Adapter Cable × 1
Jumper for Existing Chime × 1
Extension Wires × 2
Mounting Screws and Anchors × 3
Hardwire Installation Screws × 2
Doorbell Detaching Pin × 1
Mounting Wedge Screws × 5
3M Adhesive × 1
Foam Pad × 1
Wire Nuts × 2
Quick Start Guide |
| Certifications | CE, RoHS, RCM,R-NZ,FCC, EAC, Triman, UKCA |
