| CAMERA |
| Image Sensor | 1/2.8” Progressive Scan CMOS Sensor |
| Lens | Focal Length: 2.4 mm
Aperture: F2.2
Field of View: 160 (Diagonal),145°(Horizontal), 83°(Vertical) |
| Night Vision | 2× 850 nm IR LEDs (25 ft, 7.6 m)
Black and White Image |
| Interface & Button | 1× RESET Button
1× Doorbell Button
1× microSD Card Slot
1× USB Type-C Port |
| VIDEO & AUDIO |
| Maximum Resolution | 2K 3MP (2304 × 1296px) |
| Frame Rate | 15 fps |
| Digital Zoom | 10x |
| Video Compression | H.264 |
| Live View | Yes |
| Image Enhancement | 3DNR
WDR |
| Audio Input & Output | Built-in Microphone and Speaker |
| Audio Communication | Two-Way Audio with Noise Cancellation |
| STORAGE |
| Local Storage | MicroSD Card Slot on Camera (Up to 512 GB) |
| Cloud Storage | Tapo Care Cloud Storage Services (Subscription required) |
| DETECTION and NOTIFICATIONS |
| Sensor | Single PIR Motion Sensor
Motion Detection Range: 25 ft |
| AI Detection | Person and Motion Detection |
| Activity Zones | Yes |
| Output Notification | System Notification
System Notification with Snapshot (Tapo Care Services) |
| NETWORK |
| Network Connectivity | Connect via Wi-Fi |
| Wireless Connectivity | IEEE 802.11b/g/n, 2.4 GHz Wi-Fi |
| SECURITY |
| Security | On-Device Machine Learning
128-bit AES Encryption with SSL/TLS
WPA/WPA2-PSK |
| POWER |
| Power Source | 5200mAh Built-in Rechargeable Lithium-ion Battery
Optional Solar Panel: Tapo A200, A201, A202 (Sold separately) |
| Input Voltage | Doorbell Battery Pack Adapter Input: 100-240 V, 50/60 Hz |
| Output Voltage | Doorbell Battery Pack Adapter Output: 5.0 V, 1.0 A |
| GENERAL |
| Smart Integration | Google Assistant, Amazon Alexa |
| Weather Resistance | IP54 |
| System Requirements | Tapo App: iOS 9.0 or higher, Android 4.4 or higher |
| Mounting Options | Stick to a Wall
Mount to a Wall |
| Operating Temperature | -20?~45? |
| Storage Temperature | -40?~60? |
| Operating Humidity | 10%~90% RH, Non-condensing |
| Storage Humidity | 0~90% RH, Non-condensing |
| Dimensions ( W x D x H ) | Doorbell Dimensions: 5.51× 1.81 × 1.19 in (140*46*30.2mm) |
| Package Content | Tapo Video Doorbell × 1
Mounting Brackets × 1
Horizontal Mounting Wedge× 1
3M Adhesive× 1
Foam Pad× 1
Screws and Anchors
USB Cable× 1
Mounting Template Sticker × 1
Quick Start Guide |
| Certifications | CE, RoHS, RCM, R-NZ, FCC, EAC, Triman, UKCA |
