| HARDWARE FEATURES |
|
| Standards and Protocols |
• IEEE 802.3, 802.3u, 802.3ab, IEEE 802.3x, IEEE 802.1q
• TCP/IP, DHCP, ICMP, NAT, PPPoE, NTP, HTTP, HTTPS, DNS, IPSec, PPTP, L2TP, OpenVPN, SNMP |
| Interface |
• 2× 10GE SFP+ Ports (1 WAN, 1 WAN/LAN)
• 1× 1GE SFP WAN/LAN Ports
• 8× 1GE RJ45 WAN/LAN Ports
• 1× RJ45 Console Ports
• 2× USB Ports (Connecting 4G/3G Modem as WAN Backup) |
| Button |
Reset Button |
| Power Supply |
Redundant Dual Power Supplies (100–240 VAC, 50/60 Hz) |
| LED |
PWR, SYS, WAN, LAN, USB, FAN |
| Dimensions (WxDxH) |
17.3 × 8.7 × 1.7 in (440 × 220 × 44 mm) |
| BASIC FUNCTIONS |
|
| WAN Connection Type |
• Static/Dynamic IP
• PPPoE
• PPTP
• L2TP
• 6to4 Tunnel
• Pass-Through
• Mobile Broadband: 4G/3G modem for backup via USB port |
| MAC Clone |
Modify WAN/LAN MAC Address |
| DHCP |
• DHCP Server/Client
• DHCP Address Reservation
• Multi-net DHCP
• Multi-IP Interfaces |
| IPv6 |
Yes |
| VLAN |
802.1Q VLAN |
| IPTV |
IGMP v2/v3 Proxy |
| ADVANCED FUNCTIONS |
|
| ACL |
IP/Port/Protocol/Domain Name Filtering |
| Advanced Routing |
• Static Routing
• Policy Routing |
| Bandwidth Control |
• IP/Port-based Bandwidth Control
• Guarantee & Limited Bandwidth |
| Load Balance |
• Intelligent Load Balance
• Application Optimized Routing
• Link Backup (Timing, Failover)
• Online Detection |
| NAT |
• One-to-One NAT
• Multi-Net NAT
• Virtual Server
• Port Triggering
• NAT-DMZ
• FTP/H.323/SIP/IPSec/PPTP ALG, UPnP |
| Security |
• SPI Firewall
• VPN Passthrough
• FTP/H.323/PPTP/SIP/IPsec ALG
• DoS Defence, Ping of Death
• Local Management |
| Session Limit |
IP-based Session Limit |
| SECURITY |
|
| Filtering |
WEB Group Filtering
URL Filtering
Web Security |
| ARP Inspection |
• Sending GARP Packets
• ARP Scanning
• IP-MAC Binding |
| Attack Defense |
• TCP/UDP/ICMP Flood Defense
• Block TCP Scan (Stealth FIN/Xmas/Null)
• Block Ping from WAN |
| Access Control |
Source/Destination IP Based Access Control |
| AUTHENTICATION |
|
| Web Authentication |
• No Authentication
• Simple Password
• Hotspot(Local User / Voucher / SMS / Radius)
• External Radius Sever
• External Portal Sever
• Facebook Check-In
• Instagram Follow |
| MANAGEMENT |
|
| Omada App |
Yes |
| Centralized Management |
• Omada Hardware Controller (OC300)
• Omada Hardware Controller (OC200)
• Omada Software Controller
• Omada Cloud-Based Controller |
| Cloud Access |
Yes (Through OC300, OC200, Omada Software Controller, or Omada Cloud-Based Controller) |
| Service |
Dynamic DNS (Dyndns, No-IP, Peanuthull, Comexe) |
| Maintenance |
• Time Setting
• Diagnostic
• Firmware Upgrade
• Factory Defaults/Reboot
• Backup&Restore
• System Log
• Remote Management
• Statistics
• Controller Settings
• SNMP |
| Management Features |
• Automatic Device Discovery
• Intelligent Network Monitoring
• Abnormal Event Warnings
• Unified Configuration
• Reboot Schedule
• Captive Portal Configuration |
