| Tech Spec |
|
|
Panel
|
|
|
Screen Size
|
65" |
| Panel Technology |
OLED |
| Native Resolution |
3,840 X 2,160 (UHD) |
| Brightness |
1,000 / 900 / 500 / 180 nit (APL 3% / 10% / 25% / 100%) |
| Contrast Ratio |
1,850,000 : 1 |
| Color gamut |
DCI-P3 99 % |
| Viewing Angle (H x V) |
178 × 178 |
| Color Depth |
1.07 Billion Colors (10 bit) |
| Portrait / Landscape |
No / Yes |
|
Mechanical
|
|
| Specification |
|
|
Bezel Color
|
Black |
| Bezel Width |
Off Bezel : 2.0 / 2.0 / 2.0 / 2.0 mm (T/R/L/B) |
| |
On Bezel : 8.7 / 8.9 / 8.9 / 11.6 mm (T/R/L/B) |
| Weight (Head) |
31 kg |
| Weight (Head+Stand) |
35 kg |
| Packed Weight |
45.5 kg |
| Monitor Dimensions (W × H × D) |
1,446.3 × 853.8 × 56.5 mm (w/ Control Box) |
| Monitor Dimensions with Stand (W × H × D) |
1,446.3 × 896.5 × 272 mm |
| Carton Dimensions (W × H × D) |
1,670 × 200 × 1,108 mm (Box Outer Size) |
| Handle |
Yes |
| VESA™ Standard Mount Interface |
300 × 300 mm |
|
Key Feature
|
|
|
SW
|
webOS 5.0, Multi-screen (PIP, PBP (2)) |
| Picture |
Color Adjustment (OLED Light, Contrast, Chroma, Sharpness, Tint), Color Temp (VAR / 9300 K / 6500 K / 5400 K / 3200 K / D65 (6504 K) / C (6774 K) / D-Cinema (6302 K)), Over Scan (Zero Scan, Over Scan, Under Scan), Aspect Ratio (Full Wide, 4:3, 14:9, 13:9, 1.85:1, 2.35:1, 1:1, Original), AFD (Active Format Description) (Yes), Zoom (×2 ~ ×5), HDR / SDR Monitoring (Yes), 3rd Party Cal. SW Compatibility (CalMAN - Including Uniformity Compensation, 9 p / 13 p / 25 p, EBU Grade1) (LG Connect must be on.), Eyesafe Certification (Less than 50% of Blue Light Emission) (Yes), Color Accuracy : DeltaE < 2 (Yes) |
| Color |
Gamut (Native, P3, BT.709, SMPTE-C, BT.2020, EBU, Adobe RGB, NTSC), SDI Color Format (Auto, RGB444, YCbCr444, YCbCr422), R/G/B Gain (-768 ~ 255), Mono/Blue Only, Transfer Matrix, Mastering Peak, EOTF (Auto / User / 1.9 / 2.2 / 2.4 / 2.6 / SDR (Calibration) / ST.2084 PQ / BT.2100 HLG / HDR (Calibration) / Dolby Vision / Dolby Vision (Calibration)) |
| Marker |
Marker, Safety Area, Center Marker |
| Audio |
Audio Level Meter (Ch1~16, Selectable), Dolby Atmos (2Ch, Down Mix through Audio Out Port) |
| GPI |
GPI Control (General Purpose Interface) |
| Video Analysis |
Waveform, Vector Scope, Time Code (LTC, VITC), PIP/PBP |
| Advanced |
Profile Load / Save (Profile 1~10), Function Key (Function1~5), Tally, Gen Lock, LG Connect, 3rd Party Control Pad Compatibility (Open API), Remote IP Control App (HTML) |
|
Environment Conditions
|
|
|
Operation Temperature
|
0 °C to 40 °C |
| Operation Humidity |
10 % to 80 % |
|
Power
|
|
|
Power Supply
|
AC 100-240V~, 50/60Hz |
|
Power Consumption
|
|
|
Typ./Max.
|
139W (IEC 62087) / 470 W |
| BTU (British Thermal Unit) |
1,054 BTU/Hr (Typ.), 1,085 BTU/Hr (Max.) |
|
Certification
|
|
|
Safety
|
CB / NRTL |
| EMC |
FCC Class "A" / CE / KC |
| ErP |
Yes (EU Only) |
|
Software Compatibility
|
|
|
SuperSign WB
|
Yes |
| CalMAN SW Compatibility |
Yes |
| IP Remote Utility |
Yes |
|
Connectivity
|
|
|
Input
|
HDMI (2, (HDCP1.4/2.2, HDMI2.1)), SDI (4, 12G × 4, Single Link : SD / HD / 3G / 6G / 12G, Dual Link : HD / 3G_4K , Quad Link : HD_4K / 3G_4K, Quad View : SD / HD / 3G / 6G / 12G), REF (Black Burst, Tri-Level), USB 2.0 Type A (SW update, & Calibration), Power (AC) |
| Output |
Audio (Head-Phone), SDI (4, Loop-through) |
| External Control |
RS-232C In (Service Only), RJ45 (LAN, 100base-T) In, RJ45 (Remote, GPI 7port) In / Out, SFP In (SFP+, Support Only for The Embrionix's SFP Module), IR In |
|
Accessory
|
|
|
Basic
|
Remote Controller, IG (Installation Guide), Regulation Book |
